    Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners

    Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners Featured Image
    • Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners
    • Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners
    • Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners
    • Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners
    • Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners

    Short Description:

    3M 5423 is a double-sided transparent UHMW tape with a abrasion resistant backing that protects the surface from wear. 3M UHMW PE Film Tape 5423 is a thick caliper universal polyethylene tape that produces a “sliding surface” effect, making contact fray-free while reducing the squeaking caused by movement, ideal for the use because of contamination and non-lubricated applications. The effectiveness of 3M 5421 UHMW-PE film tape mainly lies in its Ultra-High Molecular Weight Polyethylene (UHMW-PE) backing, and UHMW-PE is a thermoplastic that has a unique combination of properties, such as exceptional hardness and low surface energy. 3M UHMW-PE Film Tape 5423 is a thicker version of 3M UHMW-PE Film Tape 5421.




    Download as PDF

    Product Detail

    Product Tags

    Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners

    Features

    1. Transparent color, Silicone Treated Paper liner or Densified Kraft liner for option

    2. Good initial tack for immediate bonding to material surface

    3. Powerful adhesive creates instant adhesion on countless surfaces

    4. Abrasion resistant and chemical resistance

    5. 0.3mm thickness with 610mmx33meter

    6. Reduce squeaks, rattles and other noises

    7. Good combination of flexibility

    8. Available to die cut into any shape design as per drawing

    DataSheet

    Adhesion Strength 28 N/100mm
    Adhesive Type Rubber
    Application Reducing Wear Mechanical Equipment
    Backing (Carrier) Material Polyethylene
    Elongation at Break 520%,5.3
    Maximum Operating Temperature 107 ℃/225 ℉
    Minimum Operating Temperature -34 ℃/-30 ℉
    Overall Length (Metric) 16.5 m, 16.45 m, 32.91 m, 164.59 m
    Overall Width (Metric) 51 mm, 25.4 mm, 609.6 mm,508 mm, 127 mm
    Primary Liner 60# Densified Kraft, Silicone Treated Paper
    Product Color Transparent
    Shelf Life in Months (From Date of Manufacture) 18
    Tensile Strength (Metric) 1,500 N/100mm, 963 N/100mm
    Total Tape Thickness without Liner (Metric) 0.3 mm

    Wide Application

    3M UHMW-PE 5423 Film Tape is often used in general industrial applications to help control grates and rattles caused by vibration or coating of metal and plastic materials. This UHMW-PE (Ultra High Molecular Weight Polyethylene) film provides good chemical resistance and excellent abrasion resistance, which helps to provide a long service life. 3M UHMW-PE 5423 paper tape is mounted on a support, which facilitates punching to meet the requirements of specific applications. It's ideal for applications that require low friction and movement of parts and/or materials. This slick surface tape is mainly used in aerospace, automotive, printing and MRO industries.



     Served Industries

    *Flat conveyor guide rails and chutes

    *Spray booth liners

    *Tank and bin liners

    *Drawer and cabinet slides

    *Protecting aluminum sheets on stretch forming presses
