3M Scotch Super 33 Vinyl Electrical Tape for Electrical Insulation & UV Rays Resistance

Short Description:

3M 33+ Vinyl Electrical tape is a PVC backing with 3M pressure-sensitive and rubber-resin adhesive, which provides electrical and mechanical protection. And its excellent strength and flexibility means it can stretch and recover up to 250% without breaking. It is a 0.178 mm thickness, premiun grade tape that provides electrical insulation for all wires and cables with rated voltage up to 600V. It is characterized by flame-retardant and corrosion of electrical conductors and can withstand temperatures ranging from 0 to 221°F(-18 to 105°C). Suitable for solid dielectric cable insulation, synthetic cable insulation, sheath and splicing compounds.

Send email to us Download as PDF

Product Detail

Product Tags

3M Scotch Super 33 Vinyl Electrical Tape for Electrical Insulation & UV Rays Resistance

Features

-Black color

-Overall Length:20m/33m

-Over width:19mm/25mm/38mm/50mm

-Flame-retardant and inhibits the corrosion of electrical conductors

-Elastic backing and an aggressive adhesive provides moisture-tight protection with minimum bulk

-Stretch and flexibility provide tight sealed electrical connections

-Resists UV rays, abrasion, moisture, alkalis, solvents and acids

-Withstands a temperature range of 0 to 221 °F (-18 to 105 °C)

Adhesive Type	Rubber
Application	Electrical Maintenance, Insulation
Backing (Carrier) Material	PVC
Dielectric Strength	1150 V/mil
Elongation at Break	250.0 %
Insulation Resistance	> 10^6 megohms
Maximum Operating Temperature	105 ℃/221 ℉
Minimum Operating Temperature	-18 ℃/0 ℉
Product Color	Black
Tensile Strength	15.0 lb/in(26 N/cm)
Total Tape Thickness without Liner	7mil(0.178mm)
Voltage Rating	600 V

Application Industries:

Scotch@Super 33+ Tape is commonly used in residential, light and heavy commercial and industrial environments, as well as in demanding indoor, extreme and exposed outdoor environments. It is also suitable for low and high voltage applications and cable harness applications, providing electrical and mechanical protection and providing protective sheathe for high voltage cable joints. This kind of tape is used in most electrical maintenance and insulation applications because of its strong UV resistance, wear resistance, moisture resistance, alkali resistance, solvent resistance and a variety of acids.

-solid dielectric cable insulation

-synthetic cable insulations

-jackets and splicing compounds.
